Interface Installation and Configuration 15Chapter 2
Note Many computer PCI systems have one pair of ISA and PCI slots close to
each other. This saves space and allows you to install either an ISA card or
a PCI card in the slot pair.
C. Remove the corresponding expansion slot cover from the computer
chassis (Figure 2-3).
Figure 2-2. Locating a PCI bus Expansion Slot.
PCI expansion slots
(usually white or ivory)
shared slot
Figure 2-3. Removing the PC Expansion Slot Cover.
expansion slot cover
