Chapter 2 Introducing the Aruba 8325 Switch 21
Switch product label
The switch product label is an Aruba Orange-colored tab on the bottom right side of the switch front panel. Pull the
tab out to view the product label information.
The product label information includes the part number, model number, serial number, and MAC address. The
information and bar codes are on two labels affixed to the top and bottom of the product label tab.
Figure 7: Aruba 8325 switch product label
Back of the switch
The back of the switch includes two power supply units and six fan assemblies.
Figure 8: Back of the Aruba 8325-48Y8C (JL624A, JL625A, JL857A, and JL858A)
Table 15: Aruba 8325 switch product label
Label Description
1 Product label top side. Information includes the serial number and MAC address.
2 Product label bottom side. Information includes the part number and model number.
Table 16: Back of the Aruba 8325-48Y8C (JL624A, JL625A, JL857A, and JL858A) switch labels and descriptions
Label Description
1 Power supply 2
