54 Aruba 8325 Switch Installation and Getting Started Guide
Diagnosing with the LEDs
Table 31 shows LED patterns on the switch that indicate problem conditions for general switch operation
troubleshooting.
LED patterns for general switch troubleshooting
1. Check in the table for the LED pattern you see on your switch.
2. Refer to the corresponding diagnostic tip on the next few pages.
Diagnostic tips:
Table 31: LED error indicators
LED Pattern Indicating Problems
Diagnostic Tip
PS1/PS2 LEDs Global Status Fan Port LED
Off with power
cords plugged in
–– –1
On amber
1
Flashing amber – – 2
On green Flashing amber On amber – 3
On green Flashing amber – Flashing amber 4
On green On green – Off with cable
connected
5
On green On green – On, but the port is
not communicating
6
1
Either the PS1 or PS2 LED is on amber, but not both.
Table 32: Diagnostic tips
Tip Problem Solution
1 Both switch power
supplies are not
plugged into an active
power source.
Verify the power source works by connecting it to another device. Or try
connecting the power supplies to different power sources or try different power
cords.
If the problem is still not resolved, both power supplies may be faulty.
