Cooling fans (Rear side) HP Active Cool fan technology provides superior
airflow, power and acoustic performance and is hot-
pluggable for easy upgrades.
From 4 up to 10 fans, must be installed in a specific
order of fan bay locations per how many server blades
are installed in the enclosure.
Insight Display (Front side) For easy setup and configuration of the BladeSystem
located in front of the unit.
Onboard Administrator (Rear side) Total 2 for redundant Onboard Administration providing
LAN and serial access.
Height 10U
Width 17.5 inches (445 mm) fits 19 inch rack
Depth 32 inches (813 mm)
HP GbE2c Ethernet Blade Switch
Figure 6. HP GbE2c Ethernet Blade Switch for HP c-Class BladeSystem: Part number: 410917-B21
Onboard Administrator management module
Figure 7. HP Onboard Administrator management module
10
