2–4 360201-002 Service Reference Guide, dc5000
Setup Utilities and Diagnostics Features
2.2.2 Computer Setup Menu
.
Heading Option Description
File System Information Lists product name, processor type/speed/stepping, cache
size (L1/L2), system ROM family and version, installed memory
size (number of channels (single/dual) if applicable), chassis
serial number, integrated MAC for enabled or embedded NIC
(if applicable), and asset tracking number.
About Displays copyright information.
Set Time and Date Allows you to set system time and date.
Save to Diskette Saves system configuration, including CMOS, to a formatted
blank 1.44-MB diskette in file CPQsetup.txt. Save/Restore for
Drive Key is supported.
Restore from
Diskette
Restores system configuration from a diskette. Save/Restore for
Drive Key is supported.
Set Defaults and
Exit
Restores factory default settings which includes clearing any
established passwords.
Ignore Changes
and Exit
Exits Computer Setup without applying or saving any changes.
Save Changes
and Exit
Saves changes to system configuration and exits Computer
Setup.
Storage Device
Configuration
Lists all installed BIOS controlled storage devices.
✎
SCSI storage drives will not be listed in Computer (F10)
Setup.
When a device is selected, detailed information and options
are displayed. The following options may be presented:
Diskette Type (For legacy diskette drives only)
Identifies the highest capacity media type accepted by the
diskette drive. Options are 3.5" 1.44 MB and 5.25" 1.2 MB.
Drive Emulation (IDE devices only)
Allows you to select a drive emulation type for a storage
device. (For example, a Zip drive can be made bootable by
selecting disk emulation.)
Drive Type Emulation Options
ATAPI Zip drive None (treated as Other).
Diskette (treated as diskette drive).
IDE Hard disk None (treated as Other) Disk (treated as
hard drive).
Legacy diskette No emulation options available.
IDE CD-ROM No emulation options available.
