HP COMPAQ DC5750 User Manual

6–22 437963-001 Service Reference Guide, dc5750
Removal and Replacement Procedures— Microtower (MT) Chassis
7. Release the drive by pulling the green release tab away from the drive 1 and sliding the drive
out of the bay 2.
8. Remove the four guide screws (two on each side) from the old drive. You will need these
screws to install a new drive.
9. Install the four guide screw (two on each side) that were removed from the old drive into the
new drive. The screws help guide the drive into its proper position in the bay. Extra guide
screws atre provided on the front of the chassis under the front bezel.
✎
There are a total of eight extra guide screws on the front of the chassis. Four have 6-32 standard
threads and four have M3 metric threads. Standard screws are used for hard drives and have a
silver finish. Metric screws are used for all other drives and have a black finish. Make sure to
install the appropriate guide screws into the drive.

HP COMPAQ DC5750 Specifications

General

Processor Speed	Up to 2.8 GHz
Chipset	ATI Radeon Xpress 1150
Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Processor	AMD Athlon 64 X2 / AMD Sempron
Storage	SATA Hard Drive
Optical Drive	DVD-ROM, DVD+/-RW
Operating System	Windows XP Professional
Form Factor	Small Form Factor or Microtower
USB Ports	8 USB 2.0 (2 front, 4 rear, 2 internal)
