2-26 361834-002 Technical Reference Guide
System Overview
2.4.3 Support Components
Input/output functions not provided by the chipset are handled by other support components.
Some of these components also provide “housekeeping” and various other functions as well.
Table 2-4 shows the functions provided by the support components.
2.4.4 System Memory
These systems implement a dual-channel Double Data Rate (DDR) memory architecture. All
dx6100 and dc7100 models support PC2700 (333- MHz) and PC3200 (400-MHz) DIMMs. Only
dx6120 models support DDR2, PC2-4300 (533-MHz) DIMMs.
✎
DDR and DDR2 DIMMs are NOT interchangeable. Memory type is defined by the system
board.
The USDT system provides three DIMM sockets supporting up to 3 GB of memory while all
other form factors provide four DIMM sockets and support a total of four gigabytes of memory.
✎
The maximum memory amounts stated above are with 1-GB memory modules using 1-Gb
technology DIMMs.
Table 2-4
Support Component Functions
Component Name Function
LPC47B397 I/O Controller Keyboard and pointing device I/F
Diskette I/F
Serial I/F (COM1and COM2)
Parallel I/F (LPT1, LPT2, or LPT3)
PCI reset generation
Interrupt (IRQ) serializer
Power button and front panel LED logic
GPIO ports
Processor over tempurature monitoring
Fan control and monitoring
Power supply voltage monitoring
SMBus and Low Pin Count (LPC) bus I/F
BCM5751 Ethernet Controller 10/100/1000 Fast Ethernet network interface controller.
AD1981B Audio Codec Audio mixer
Digital-to-analog converter
Analog-to-digital converter
Analog I/O
6-channel audio support
