HP Compaq dc7100 DT Technical Reference Guide

2-32 361834-002 Technical Reference Guide
System Overview
Table 2-10
Optical Drive Specifications
Parameter 48x CD-ROM 48/24/28x CD-RW Drive
Interface Type IDE IDE
Media Type (reading) Mode 1,2, Mixed Mode, CD-DA,
Photo CD, Cdi, CD-XA
Mode 1,2, Mixed Mode, CD-DA,
Photo CD, Cdi, CD-XA
Media Type (writing) N/a CD-R, CD-RW
Transfer Rate (Reads) 4.8 Kb/s (max sustained) CD-ROM, 4.8 Kb/s;
CD-ROM/CD-R, 1.5-6 Kb/s
Transfer Rate (Writes): N/a CD-R, 2.4 Kbps (sustained);
CD-RW, 1.5 Kbps (sustained);
Capacity:
Mode 1, 12 cm
Mode 2, 12 cm
8 cm
550 MB
640 MB
180 MB
650 MB @ 12 cm
Center Hole Diameter 15 mm 15 mm
Disc Diameter 8/12 cm 8/12 cm
Disc Thickness 1.2 mm 1.2 mm
Track Pitch 1.6 um 1.6 um
Laser
Beam Divergence
Output Power
Type
Wave Length
+/- 1.5 °
0.14 mW
GaAs
790 +/- 25 nm
53.5 + 1.5°
53.6 0.14 mW
GaAs
790 +/- 25 nm
Average Access Time:
Random
Full Stroke
<100 ms
<150 ms
<120 ms
<200 ms
Audio Output Level 0.7 Vrms 0.7 Vrms
Cache Buffer 128 KB 128 KB

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
