HP Compaq dc7100 DT Technical Reference Guide

Technical Reference Guide 361834-002 2-33
System Overview
Table 2-11
Hard Drive Specifications
Parameter 40 GB 80 GB 160 GB
Drive Size 3.5 in 3.5 in 3.5 in
Interface SATA SATA SATA
Transfer Rate 150 MB/s 150 MB/s 150 MB/s
Drive Protection System
Support?
Yes Yes Yes
Typical Seek Time (w/settling)
Single Track
Average
Full Stroke
1.2 ms
8.0 ms
18 ms
0.8 ms
9.0 ms
17 ms
0.8 ms
9 ms
17 ms
Disk Format (logical blocks) 78,165,360 156,301,488 320,173,056
Rotation Speed 5400/7200 5400/7200 7200 RPM
Drive Fault Prediction SMART III SMART III SMART III

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
