Hardware Reference Guide www.hp.com 2–19
Hardware Upgrades
7. To remove an expansion slot cover:
a. If the latch is not open, squeeze the sides of the latch together
to release it 1.
b. Open the latch 2.
c. Pull the expansion card slot cover straight up out of the
expansion card assembly 3.
Removing an Expansion Card Slot Cover
