HP Compaq dc7100 DT Hardware Reference Guide

2–24 www.hp.com Hardware Reference Guide
Hardware Upgrades
7. Pull the hard drive latch toward the front of the computer 1.
8. Rotate the right side of the hard drive up until it stops 2, then pull
the drive out to the right 3.
Removing the Internal Hard Drive

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
