HP Compaq Elite 8300 All-in-One User Manual

7. Remove the Torx screw (1) that secures the Mylar that covers the power button board, and then
lift the Mylar from the computer (2).
NOTE: On some models, the left screw that secures the left speaker (when viewed from the
rear) may also secure the Mylar.
Figure 7-71 Removing the Mylar shield
92 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis

HP Compaq Elite 8300 All-in-One Specifications

General

Brand	HP
Model	Compaq Elite 8300 All-in-One
Category	Desktop
Language	English
