HP Compaq Elite 8300 All-in-One User Manual

Stand
The stand is secured with two captive Torx screws. You must remove a plastic cover to gain access
to the screws. You must remove the access panel to remove the stand.
To remove the stand:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 32).
2. Remove the access panel (see
Access panel on page 36).
3. Push the release button (1) on the bottom of the stand and pull the back of the stand off (2).
Figure 7-9 Removing the back of the stand
4. Push the base of the stand down (1), and loosen the two captive Torx screws securing the stand
to the chassis (2).
Figure 7-10 Releasing the stand
38 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis

HP Compaq Elite 8300 All-in-One Specifications

General

RAM	Up to 16 GB DDR3
Network	Integrated Intel 82579LM Gigabit Ethernet
Chipset	Intel Q77 Express
Processor	Intel Core i5-3470S
Storage	128 GB SSD, 256 GB SSD
Display	23-inch Full HD (1920 x 1080)
Graphics	Intel HD Graphics 2500
Operating System	Windows 7 Professional
Optical Drive	DVD+/-RW SuperMulti
USB Ports	6 x USB 2.0
Wireless	802.11a/b/g/n
Audio	Integrated High Definition Audio, Internal Speaker
Ports	VGA, DisplayPort, RJ-45, audio in/out
