Power button board
The power button board is located on the bottom left corner of the computer. It is covered by a Mylar
shield and has two connectors and one screw.
Figure 7-70 Power button board location
To remove the power button board:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 32).
2. Remove the access panel (see
Access panel on page 36).
3. Remove the stand (see
Stand on page 38).
4. Remove the lower panel (see
Lower panel on page 40).
5. Remove the optical drive (see
Replacing the optical disc drive on page 47).
6. Remove the left side panel (see
Side panels on page 78).
Power button board 91
