12. Remove the Torx screws that secure the bezel to the main system bracket assembly, as follows:
Model 6300: 11 total screws
Left: 2 screws
Top: 4 screws
Right 2 screws
Bottom: 2 screw
Figure 7-74 Front bezel assembly screw locations – 6300 models
Model 8300: 14 total screws
Left: 4 screws
Top: 4 screws
Front bezel 95

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq Elite 8300 All-in-One and is the answer not in the manual?

HP Compaq Elite 8300 All-in-One Specifications

General IconGeneral
RAMUp to 16 GB DDR3
NetworkIntegrated Intel 82579LM Gigabit Ethernet
ChipsetIntel Q77 Express
ProcessorIntel Core i5-3470S
Storage128 GB SSD, 256 GB SSD
Display23-inch Full HD (1920 x 1080)
GraphicsIntel HD Graphics 2500
Operating SystemWindows 7 Professional
Optical DriveDVD+/-RW SuperMulti
USB Ports6 x USB 2.0
Wireless802.11a/b/g/n
AudioIntegrated High Definition Audio, Internal Speaker
PortsVGA, DisplayPort, RJ-45, audio in/out
