R
emo
v
al and Replace
ment Pr
ocedures
Maintenance and S
ervi
ce Guide
6–5
5
2.
Remov
e the four T8M2.0×5.0 scre
ws
1
that secure the
system board to the notebook.
3.
Remov
e the T8M2.0×7.5 scre
w
2
that secures the system
board spacer to the notebook.
4.
Remov
e the system board spacer
3
.
R
emo
v
ing the S
ys
tem Boar
d Sc
r
ew
s
143
145
