6–4 Maintenance and Service Guide
Removal and Replacement Procedures
Section Description
# of Screws Removed
5.15 Processor 0
5.16 Modem Board 2
5.17 Internal Memory Module 0
5.18 TouchPad 0
5.19 Mini PCI Communications
Module
0
Å
To prevent an unresponsive system and the display of a
warning message, install only a Mini PCI device authorized
for use in your computer by the governmental agency that
regulates wireless devices in your country. If you install a
device and then receive a warning message, remove the
device to restore computer functionality. Then contact
Customer Care.
5.20 Display Assembly 6
5.21 To p C o ve r 11
5.22 Serial Connector Module 2 screw locks
5.23 Audio Board 0
5.24 System Board 2 screw locks
4 screws
Disassembly Sequence Chart
(Continued)
To Next Page
