HP Compaq nc6220 Maintenance And Service Guide

Removal and Replacement Procedures
Maintenance and Service Guide 6–33
6.18 TouchPad
1. Prepare the computer for disassembly (Section 6.3).
2. Remove the keyboard (Section 6.9).
3. Press down on the section of the top cover 1 to the left of the
metal tab next to the TouchPad .
4. Lift up on the metal tab 2 on the TouchPad until the
TouchPad disengages from the top cover.
Releasing the TouchPad
TouchPad Spare Part Number Information
TouchPad (includes TouchPad cable) 379798-001

HP Compaq nc6220 Specifications

General

Display	14.1-inch TFT
Maximum Memory	4 GB
Hard Drive Interface	ATA-100
Graphics	Intel Graphics Media Accelerator 900
Operating System	Windows XP Professional
Battery Life	Up to 4 hours
Processor	Intel Pentium M
Display Resolution	1024 x 768
Storage	40 GB
Networking	10/100/1000 Ethernet, 802.11b/g Wi-Fi
Ports	3 x USB 2.0, VGA, RJ-11, RJ-45, headphone/microphone jacks
Optical Drive	DVD-ROM
RAM	512 MB to 2 GB
