6–46 Maintenance and Service Guide
Removal and Replacement Procedures
6.23 Audio Board
1. Prepare the computer for disassembly (Section 6.3)
and remove the following components:
a. Hard drive (Section 6.4)
b. Keyboard (Section 6.9)
c. Switch cover (Section 6.10)
d. TouchPad (Section 6.18)
e. Display assembly (Section 6.20)
f. Top cover (Section 6.21)
Audio Board Spare Part Number Information
For use with system boards with discrete video memory
For use with system boards with UMA video memory
385498-001
379811-001
