HP Compaq nc6220 Maintenance And Service Guide

6–44 Maintenance and Service Guide
Removal and Replacement Procedures
6.22 Serial Connector Module
1. Prepare the computer for disassembly (Section 6.3)
and remove the following components:
a. Hard drive (Section 6.4)
b. Keyboard (Section 6.9)
c. Switch cover (Section 6.10)
d. TouchPad (Section 6.18)
e. Display assembly (Section 6.20)
f. Top cover (Section 6.21)
Serial Connector Module Spare Part Number Information
Serial connector module (includes serial connector
module cable)
378227-001

HP Compaq nc6220 Specifications

General

Display	14.1-inch TFT
Maximum Memory	4 GB
Hard Drive Interface	ATA-100
Graphics	Intel Graphics Media Accelerator 900
Operating System	Windows XP Professional
Battery Life	Up to 4 hours
Processor	Intel Pentium M
Display Resolution	1024 x 768
Storage	40 GB
Networking	10/100/1000 Ethernet, 802.11b/g Wi-Fi
Ports	3 x USB 2.0, VGA, RJ-11, RJ-45, headphone/microphone jacks
Optical Drive	DVD-ROM
RAM	512 MB to 2 GB
