HP Compaq nc6220 Maintenance And Service Guide

Removal and Replacement Procedures
Maintenance and Service Guide 6–27
✎
The thermal paste should be thoroughly cleaned from the
surfaces of the heat sink 1 and processor 2 each time the heat
sink is removed. Thermal paste is included with all heat sink
and processor spare part kits.
Replacing the Thermal Paste
Reverse the above procedure to install the heat sink.

HP Compaq nc6220 Specifications

General

Display	14.1-inch TFT
Maximum Memory	4 GB
Hard Drive Interface	ATA-100
Graphics	Intel Graphics Media Accelerator 900
Operating System	Windows XP Professional
Battery Life	Up to 4 hours
Processor	Intel Pentium M
Display Resolution	1024 x 768
Storage	40 GB
Networking	10/100/1000 Ethernet, 802.11b/g Wi-Fi
Ports	3 x USB 2.0, VGA, RJ-11, RJ-45, headphone/microphone jacks
Optical Drive	DVD-ROM
RAM	512 MB to 2 GB
