HP Compaq nc6220 Maintenance And Service Guide

C–2 Maintenance and Service Guide
Screw Listing
Phillips PM1.5×4.0 Screw Locations
Table C-1
Phillips PM1.5×4.0 Screw
Color Qty. Length Thread
Head
Width
Black 5 4.0 mm 1.5 mm 4.5 mm
Where used:
2 screws that secure the hard drive cover to the computer (screws are captured
on the cover by C clips; documented in Section 6.4)
mm

HP Compaq nc6220 Specifications

General

Display	14.1-inch TFT
Maximum Memory	4 GB
Hard Drive Interface	ATA-100
Graphics	Intel Graphics Media Accelerator 900
Operating System	Windows XP Professional
Battery Life	Up to 4 hours
Processor	Intel Pentium M
Display Resolution	1024 x 768
Storage	40 GB
Networking	10/100/1000 Ethernet, 802.11b/g Wi-Fi
Ports	3 x USB 2.0, VGA, RJ-11, RJ-45, headphone/microphone jacks
Optical Drive	DVD-ROM
RAM	512 MB to 2 GB
