HP Compaq nc6220

C–12 Maintenance and Service Guide
Screw Listing
Torx 8 T8M2.0×8.0 Screw Locations
Table C-5
Torx8 T8M2.0×8.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 21 8.0 mm 2.0 mm 4.0 mm
Where used:
4 screws that secure the system board to the computer (documented in
Section 6.24)
mm
