HP Compaq nc6220 - Page 203

Screw Listing
Maintenance and Service Guide C–17
Phillips PM2.0×7.0 Screw Locations
Table C-9
Phillips PM2.0×7.0 Screw
Color Qty. Length Thread
Head
Width
Silver 2 7.0 mm 2.0 mm 4.5 mm
Where used:
2 screws that secure the fan to the computer (screws are captured on the
fan assembly by an O clip; documented in Section 6.13)
mm
