5–32 Maintenance and Service Guide
Removal and Replacement Procedures
5.14 Processor
1. Prepare the notebook for disassembly (Section 5.3).
2. Release the keyboard (Section 5.9).
3. Remove the thermal plate (Section 5.12).
4. Remove the heat sink (Section 5.13).
Processor Spare Part Number Information
Intel Pentium M 770 (2.13-GHz)
Intel Pentium M 760 (2.00-GHz)
Intel Pentium M 750 (1.86-GHz)
Intel Pentium M 740 (1.73-GHz)
Intel Pentium M 730 (1.60-GHz)
378224-001
378223-001
378222-001
378221-001
378220-001
