5–42 Maintenance and Service Guide
Removal and Replacement Procedures
5.19 Display Assembly
1. Prepare the notebook for disassembly (Section 5.3)
and remove the following components:
a. Keyboard (Section 5.9)
b. Switch cover (Section 5.10)
c. TouchPad (Section 5.17)
Display Assembly Spare Part Number Information
15.4-inch, SWXGA, TFT
15.4-inch, WXGA, TFT
15.4-inch, UXGA, TFT
382684-001
382682-001
382683-001
To Next Page
