Product Description
Maintenance and Service Guide 1–11
The external components on the rear panel of the notebook are
shown below and described in Table 1-4.
Rear Panel Components
Table 1-4
Rear Panel Components
Item Component Function
1 Primary battery bay Holds the primary battery pack.
2 Power connector Connects an AC adapter or an optional
automobile or aircraft adapter.
3 External monitor port Connects an optional external VGA
monitor or projector.
