Removal and Replacement Procedures
Maintenance and Service Guide 5–67
5.26 Audio Board
1. Prepare the notebook for disassembly (Section 5.3)
and remove the following components:
a. Hard drive (Section 5.4)
b. MultiBay II device (Section 5.6)
c. Bluetooth board (Section 5.8)
d. Switch cover (Section 5.10)
e. Keyboard (Section 5.9)
f. Thermal plate (Section 5.12)
g. Heat sink (Section 5.13)
h. TouchPad (Section 5.17)
i. Display assembly (Section 5.19)
j. Top cover (Section 5.20)
k. System board (Section 5.22)
Audio Board Spare Part Number Information
Audio board (includes audio board cable) 382677-001
