5–46 Maintenance and Service Guide
Removal and Replacement Procedures
5.20 Top Cover
1. Prepare the notebook for disassembly (Section 5.3)
and remove the following components:
a. Hard drive (Section 5.4)
b. Keyboard (Section 5.9)
c. Switch cover (Section 5.10)
d. TouchPad (Section 5.17)
e. Display assembly (Section 5.19)
2. Turn the notebook upside down with the front panel
toward you.
Top Cover Spare Part Number Information
For use only with HP Compaq nw8240 models
For use only with HP Compaq nc8230 and nc8220 models
382679-001
382678-001
