Illustrated Parts Catalog
Maintenance and Service Guide 3–19
3.7 Sequential Part Number Listing
Screw Kit (includes the following screws; refer to
Appendix C, “Screw Listing,” for more information on
specifications and usage)
382692-001
■ Hex socket HM5.0×12.0 screw lock
■ Phillips PM3.0×5.0 screw
■ Phillips PM3.0×4.0 screw
■ Phillips PM2.5×13.0 spring-loaded
screw
■ Phillips PM2.0×10.0 spring-loaded
screw
■ Phillips PM2.0×8.0 shoulder screw
■ Phillips PM2.0×6.0 screw
■ Phillips PM2.0×5.0 screw
■ Phillips PM2.0×4.0 screw
■ Phillips PM2.0×2.0 screw
■ Phillips PM1.5×4.0 screw
■ Phillips PM1.5×3.0 screw
■ Torx 8 M2.0×9.5 screw
■ Torx 8 M2.0×6.0 screw
■ Torx 8 M2.0×4.0 screw
Table 3-5
Spare Part Information
(Continued)
Description
Spare Part
Number
Table 3-6
Sequential Part Number Listing
Spare Part
Number Description
246959-001 Power cord for use in Canada, French Canada, Latin America,
Taiwan, Thailand, and the United States
246959-011 Power cord for use in Australia and New Zealand
246959-021 Power cord for use in Belgium, Europe, Finland, France,
Germany, Greece, the Netherlands, Norway, Portugal, Spain,
and Sweden
246959-031 Power cord for use in Hong Kong and the United Kingdom
To Next Page
