C–2 Maintenance and Service Guide
Screw Listing
Phillips PM2.0×4.0 Screw Locations
Table C-1
Phillips PM2.0×4.0 Screw
Color Qty. Length Thread
Head
Width
Black 3 4.0 mm 2.0 mm 4.0 mm
Where used:
1 Two screws that secure the hard drive cover to the notebook (screws are
captured on the cover by C clips; documented in Section 5.3)
2 One screw that secures the memory module compartment cover to the
notebook (screw is captured on the cover by C clips; documented in
Section 5.7)
mm
