C–4 Maintenance and Service Guide
Screw Listing
Phillips PM3.0×5.0 and PM3.0×4.0 Screw Locations
Table C-3
Phillips PM3.0×5.0 Screw
Color Qty. Length Thread
Head
Width
Silver 2 5.0 mm 3.0 mm 5.0 mm
Where used:
1 Two screws that secure the hard drive frame to the hard drive (documented in
Section 5.3)
mm
Table C-4
Phillips PM3.0×4.0 Screw
Color Qty. Length Thread
Head
Width
Silver 2 5.0 3.0 mm 5.0 mm
Where used:
2 Two screws that secure the hard drive frame to the hard drive (documented in
Section 5.3)
mm
