Screw Listing
Maintenance and Service Guide C–19
Phillips PM2.0×10.0 Spring-Loaded Screw Locations
Table C-10
Phillips PM2.0×10.0 Spring-Loaded Screw
Color Qty. Length Thread
Head
Width
Silver 4 10.0 mm 2.0 mm 5.0 mm
Where used:
4 screws that secure the thermal plate to the notebook (documented in
Section 5.12)
mm
