5–6 Maintenance and Service Guide
Removal and Replacement Procedures
4. Remove the battery pack by following these steps:
a. Turn the notebook upside down with the rear panel
toward you.
b. Slide and release the battery pack lock latch 1 to the right.
(The battery pack partially disengages from the
notebook.)
c. Slide and hold the battery pack release latch 2 to the
right.
d. Slide the battery pack straight back 3 and remove it.
Removing the Battery Pack
Reverse the above procedure to install the battery pack.
