Removal and Replacement Procedures
Maintenance and Service Guide 5–13
3. Loosen the PM2.0×4.0 screw 1 that secures the memory
module compartment cover to the notebook.
4. Lift the right side of the cover up and swing it to the left 2.
5. Remove the memory module compartment cover.
✎
The memory module compartment cover is included in the
Miscellaneous Plastics Kit, spare part number 382691-001.
Removing the Memory Module Compartment Cover
