HP Compaq NX7300 - Hex HM5.0×12.0 Screw Lock

A–22 Maintenance and Service Guide
Screw Listing
Hex HM5.0×12.0 Screw Lock Locations
Table A-15
Hex HM5.0×12.0 Screw Lock
Color Qty. Length Thread
Head
Width
Silver 2 12.0 mm 5.0 mm 5.0 mm
Where used:
2 screw locks that secure the system board to the computer (documented in
Section 5.21)
mm
