Removal and Replacement Procedures
Maintenance and Service Guide 5–43
7. Remove the four TM2.5 × 5.0 screws
1
that secure the
TouchPad, TouchButton board, and TouchPad bracket to the
palm rest (Figure 5-33).
8. Remove the TouchPad bracket
2
, TouchButton board
3
, and
TouchPad
4
from the palm rest.
Figure 5-33. Removing the TouchPad Components on
TouchPad Models
