Maintenance and Service Guide C–5
Figure C-4. TM2.5 × 5.0 Screw Locations
Table C-1
Torx T8 Metric 2.5 × 5.0 Screw
(Continued)
Color Qty Length Thread
Head
Width
Silver 30 5.0 mm 2.5 mm 5.0 mm
Where used:
One screw that secures the display inverter cable ground loop to the heat
spreader (documented in Section 5.13)
