Cable Connections
System board connectors are color-coded to make it easier to find the proper connection.
Connector Name
Connector Color Description
ATXPOWER White Power supply, 24-pin
ATX_CPU White Power supply, 4-pin
FLOPPY Black Diskette drive
CHASSIS_FAN1 Brown Chassis fan
CPU FAN White Heatsink fan
F_PANEL Black Front power button/LED
F_USB1 White Front I/O USB cable
F_AUDIO Yellow Front I/O audio
SPEAKER White Internal speaker
F_1394 Red Serial port
F_USB2 Black Media card reader
SATA0 dark blue Primary hard drive
SATA1 white Primary optical drive
SATA4 red Second hard drive
SATA5 black Second optical drive
50 Chapter 7 Removal and Replacement Procedures Microtower (MT) Chassis
