2-6 www.hp.com Technical Reference Guide
System Overview
Figure 2-3 shows the front panel components of the Small Form Factor (SFF). and Slim Tower
(ST)
Figure 2-3. HP Compaq dc7700 SFF (left)/dx7300 ST (right) Front View
Item Description Item Decription
1 Diskette drive activity LED 7 Microphone audio In jack
2 Diskette drive media door 8 Headphone audio Out jack
3 CD-ROM drive acitvity LED 9 USB ports 7, 8
4 Diskette drive eject button 10 Hard drive activity LED
5CD-ROM media tray 11Power LED
6 CD-ROM drive open/close button 12 Power button
