Appendix
Specifications
48
Weight and Dimensions
System Processing Unit (SPU)
Height 445 mm (17.5 in)
Width 191 mm (7.5 in)
Depth 451 mm (17.75 in)
Weight 14 kg (30.8 lb). Weight excludes monitor and
keyboard.
System footprint
0.08 m
2
(0.9 ft
2
)
Keyboard
Height 35 mm (1.4 in)
Width 467 mm (18.4 in)
Depth 198 mm (7.8 in)
Weight 1.9 kg (4.2 lb)
Cable Length
Keyboard cable 2 m (6.6 ft)
Power Supply Specifications
HP NetServer E 30
Power supply input voltage 100 to 127 VAC ~ 5 A at 50/60 Hz
200 to 240 VAC ~ 3 A at 50/60 Hz
Manual switching between 115 and 230 V
Power supply output 160 W continuous maximum
200 W peak
HP NetServer E 40
Power supply input voltage 100 to 127 VAC ~ 5 A at 50/60 Hz
200 to 240 VAC ~ 2.85 A at 50/60 Hz
Manual switching between 115 and 230 V
Power supply output 200 W continuous maximum
224 W peak
