5. Lift the rear cover, take off the tapes and disconnect the connectors.
6. Tear off the tapes carefully.
7. Remove the pins and remove the screw.
8. Remove the screws and disconnect the pin to remove the mainframe.
9. Remove the Mylar
10. Unscrew the screws to remove the main board and power board.
11. Remove the connect pins.
12. Unscrew the screws to remove the middle frame and Panel
13. Remove the DECO_BEZEL.
14. Remove the screws and disconnect the pins to remove the Webcam Module.
15. Remove the Connector Board
16. Tear off the tapes, unscrew the screws and remove the cable.
17. Unscrew the screws. Disconnect the pins
18. Unscrew the screws and disconnect the in to remove the USB board.
19. Remove the screws and take off the tapes to remove the speaker
20. Unscrew the screw and disconnect the pin to remove the Audio board.
3.2 Location of components requiring selective treatment. The photos and/or graphics below identify the location of the parts or
components requiring selective treatment within the main unit. For End-of-Life product disassembly instructions of external
accessories including external power supply (EPS), external keyboard (KB) external mouse and external cables and cords, refer to the
following URL:
End-of-Life Product Disassembly Instructions (hp.com)
12. Mechanical Instructions
1. Precaution
Please read the precautions as follows to prevent any damages to the LCD Monitor.
Make sure all power connection is removed. Be sure that the LCD Monitor is in power off status.
