HP4402.book : chapter3.fm 3 Thu Feb 11 15:53:59 1999
Menu Reference
The Front Panel Menu Maps
HP E4418B User’s Guide 3-3
The Front Panel Menu Maps
The following diagrams detail the structure of the softkey menus which
are accessed through the following seven hardkeys:
Note On your power meter some softkey labels have numeric values
displayed under them. These values show the current setting of
that softkey. Since these values are variable they are shown in a
grayed out text on the following menu maps.
dBm/W Menu
Note Depending on the power meter’s setup you will be unable to select
certain softkeys. The text on these softkey labels appears grayed
out. Refer to the appropriate softkey descriptions for further
information.
dBm/W
Frequency
Cal Fac
Meas
Setup
Rel
Offset
Save
Recall
System
Inputs
Zero
Cal
dBm
W
dB
%
dBm/W
