Specifications
General
5-16 HP E4418B User’s Guide
General
Dimensions
The following dimensions exclude front and rear panel protrusions:
212.6 mm W x 88.5 mm H x 348.3 mm D (8.5 in x 3.5 in x 13.7 in)
Weight
Net
4.0 Kg (8.8 lb)5.0 Kg (11 lb) with option 001
Shipping
7.9 Kg (17.4 lb)8.9 Kg (19.6 lb) with option 001
Safety
Conforms to the following Product Specifications:
• EN61010-1: 1993/IEC 1010-1:1990+A1/CSA C22.2 No.
1010-1:1993
• EN60825-1: 1994/IEC 825-1: 1993 Class 1
• Low Voltage Directive 72/23/EEC
Remote Programming
Interface
HP-IB interface operates to IEEE 488.2. RS-232 and RS-422 interfaces
are supplied as standard.
Command Language
SCPI standard interface commands. HP 437B code compatible.
HP-IB Compatibility
SH1, AH1, T6, TE0, L4, LE0, SR1, RL1, PP1, DC1, DT1, C0
