HP4402.book : chapter2.fm 16 Thu Feb 11 15:53:59 1999
Power Meter Operation
Making Measurements with the HP E-Series Power Sensors
2-16 HP E4418B User’s Guide
Example
To make a measurement using an HP E-series power sensor. The
frequency of the signal to be measured is 100 MHz.
• Disconnect the power sensor from any source.
• Press .
• Press .
• Connect the power sensor to the POWER REF output.
• Press .
• Press , . Use the , , and
hardkeys to enter 100. Press .
• Connect the power sensor to the signal to be measured.
• The measurement result is now displayed.
Zero
Cal
Zero
Cal
Frequency
Cal Fac
Freq
MHz
To Next Page
