ENWW
Front Panel Controls
Table 4-1 Monitor Front Panel Controls
Control Function
1 Menu/Select Opens, selects or exits the OSD menu.
2 – (Minus)/Auto
●
Navigates backward through the OSD menu and
decreases adjustment levels.
●
When the OSD menu is inactive, activates the auto
adjustment feature to optimize the screen image.
3 + (Plus) Navigates forward through the OSD menu and increases
adjustment levels.
4 Input Select Selects the video input (DVI-I #1 or DVI-I #2).
5 Power LED Fully powered = Green.
Sleep mode = Amber.
Sleep Timer mode = Flashing Amber.
6 Power Turns the monitor on or off.
22 Chapter 4 Operating the Monitor
