HP EliteBook 8440P Maintenance And Service Guide

Computer Setup
Maintenance and Service Guide 5–9
Restoring factory settings in Computer Setup
✎
Restoring defaults will not change the hard drive mode.
To return all settings in Computer Setup to the values configured at the factory, follow these steps:
1. Turn on or restart the computer, and then press
esc while the “Press the ESC key for Startup Menu” message is
displayed at the bottom of the screen.
2. Press
f10 to enter BIOS Setup.
3. Use a pointing device or the arrow keys to select File > Restore Defaults.
4. Follow the on-screen instructions.
5. To save your changes and exit, click the Save icon in the lower-left corner of the screen, and then follow the
on-screen instructions.
– or –
Use the arrow keys to select File > Save Changes and Exit, and then press
enter.
Your changes go into effect when the computer restarts.
✎
Your password settings and security settings are not changed when you restore the factory settings.
Computer Setup menus
The menu tables in this section provide an overview of Computer Setup options.
✎
Some of the Computer Setup menu items listed in this chapter may not be supported by your computer.
File menu
Select To do this
System Information ■ View identification information for the computer and the
batteries in the system.
■ View specification information for the processor, cache and
memory size, system ROM, video revision, and keyboard
controller version.
Set System Data and Time ■ Set or change the date and time on the computer.
System Diagnostics ■ System Information
❐ Identification information for the computer and the
batteries in the system.
❐ Specification information for the processor, cache and
memory size, system ROM, video revision, and
keyboard controller version.
■ Start-up Test—Verifies the system components needed for
starting the computer.
■ Run-In Test—Runs a comprehensive check on system
memory.
■ Hard Disk Test—Runs a comprehensive self-test on any
hard drive in the system.
(Continued)

HP EliteBook 8440P Specifications

General

HDD speed	7200 RPM
HDD interface	SATA II
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-620M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
Display diagonal	14 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Discrete graphics card model	NVIDIA Quadro HD 6310
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
Discrete graphics card memory	0.512 GB
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Graphics card family	NVIDIA
Intel segment tagging	Enterprise
Audio system	HP Premier Sound
Bluetooth version	2.1+EDR
Networking features	Gigabit Ethernet
Mobile network generation	3G
Operating system installed	Windows 7 Professional
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	-
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
Product color	Silver
Country of origin	China
Keyboard layout	QWERTY
Pointing device	Touchpad
Processor code	SLBPE
Processor ARK ID	43560
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	236 mm
Width	336 mm
Weight	2120 g
Height (front)	31 mm
