3–12 Maintenance and Service Guide
Illustrated parts catalog
Mass storage devices
Item Description Spare part number
(1) Hard drives (includes bracket, screws, and sponge material)
250-GB 7200-rpm SATA hard drive 594044-001
320-GB 7200-rpm SATA hard drive 594045-001
500-GB 7200-rpm SATA hard drive 594046-001
(2) Optical drives (includes drive bezel, bracket, and rubber covers)
Blu-ray ROM with LightScribe DVD±RW SuperMulti DL Drive 594040-001
Blu-ray R/RE DVD±RW SuperMulti Drive 594041-001
DVD-ROM Drive 594042-001
DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe 594043-001
(3) Solid-state drives
160-GB solid-state drive 594047-001
256-GB solid-state drive 594048-001
