Phillips PM2.0×5.0 captive screw
Color Quantity Length Thread Head diameter
Black 4 5.0 mm 2.0 mm 4.5 mm
Where used:
(1) Two screws that secure the hard drive cover to the computer (screws are captured on the cover by
C-clips)
(2) Two screws that secure the memory module compartment cover to the computer (screws are
captured on the cover by C-clips)
114 Chapter 7 Screw listing
