Page #143 background imageLoading...
Page #143 background image
The screen image is added to the document.
4. Save the document.
When backing up to discs, use any of the following types of discs (purchased separately): CD-R,
CD-RW, DVD+R, DVD+R DL, DVD-R, DVD-R DL, or DVD±RW. The discs you use will depend on
the type of optical drive installed in your computer.
NOTE: DVDs and DVDs with double-layer (DL) support store more information than CDs, so
using them for backup reduces the number of recovery discs required.
When backing up to discs, number each disc before inserting it into the optical drive of the computer.
To create a backup using Backup and Restore Center, follow these steps:
NOTE: Be sure that the computer is connected to AC power before you start the backup process.
NOTE: The backup process may take over an hour, depending on file size and the speed of the
computer.
1. Select Start > All Programs > Maintenance > Backup and Restore Center.
2. Follow the on-screen instructions to back up your entire computer (select models only) or your files.
NOTE: Windows® includes the User Account Control feature to improve the security of your
computer. You may be prompted for your permission or password for tasks such as installing
software, running utilities, or changing Windows settings. Refer to Help and Support for more
information.
Performing a recovery
In case of system failure or instability, the computer provides the following tools to recover your files:
Windows recovery tools: You can use the Backup and Restore Center to recover information you
have previously backed up. You can also use Windows Startup Repair to fix problems that might
prevent Windows from starting correctly.
f11 recovery tools: You can use the f11 recovery tools to recover your original hard drive image.
The image includes the Windows operating system and software programs installed at the factory.
NOTE: If you are unable to boot (start up) your computer, you must purchase a Windows Vista
operating system DVD to reboot the computer and repair the operating system. For additional
information, refer to the “Using a Windows Vista operating system DVD (purchased separately)” section
in this guide.
Using the Windows recovery tools
To recover information you previously backed up, follow these steps:
1. Click Start > All Programs > Maintenance > Backup and Restore Center.
2. Follow the on-screen instructions to recover your entire computer (select models only) or your files.
NOTE: Windows includes the User Account Control feature to improve the security of your computer.
You may be prompted for your permission or password for tasks such as installing software, running
utilities, or changing Windows settings. Refer to Help and Support for more information.
To recover your information using Startup Repair, follow these steps:
Backup and recovery in Windows Vista 135

Table of Contents

Other manuals for HP EliteBook 8530p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8530p and is the answer not in the manual?

HP EliteBook 8530p Specifications

General IconGeneral
Bus typeFSB
SteppingE0
Tjunction105 °C
Processor cache6 MB
Processor cores2
Processor modelT9400
System bus rate- GT/s
Processor familyIntel® Core™2 Duo
Processor seriesIntel Core 2 Duo T9000 Series
Processor socketSocket 479
Processor codenamePenryn
Processing Die size107 mm²
Processor frequency2.53 GHz
Processor cache typeL2
Processor technologyIntel Centrino 2 w/ vPro
Processor lithography45 nm
Processor manufacturerIntel
Processor front side bus1066 MHz
Processor operating modes64-bit
ECC supported by processorNo
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)9.5
Number of Processing Die Transistors410 M
Motherboard chipsetIntel® PM45 Express
HDD speed7200 RPM
HDD interfaceSATA II
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity250 GB
Display surfaceMatt
Display diagonal15.4 \
Display resolution1680 x 1050 pixels
Native aspect ratio16:10
TypePC
Minimum RAM1000 MB
Modem speed56 Kbit/s
Battery type8-cell (73 WHr) Lithium-Ion
Expansion slots1 Express Card/54; 1 media card reader
Rear ports note1 external VGA monitor; 1 AC power
Size (imperial)14 \
Power management8-cell (73 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Power supply typeExternal 120-watt Smart AC adapter; HP Fast Charge
Weight (imperial)Weight varies by configuration and component. Starting at 6.3 lb lbs
Dimensions (WxDxH)355 x 263.5 x 28.2 mm
Wireless technology802.11a/b/g/n
Manageability featuresHP 3D DriveGuard
Compatible operating systemsGenuine Windows Vista Business 64; Genuine Windows Vista Enterprise
Memory slots2x SO-DIMM
Internal memory2 GB
Internal memory typeDDR2-SDRAM
Maximum internal memory8 GB
Discrete graphics card modelAMD Mobility Radeon HD 3650
Maximum graphics card memory0.256 GB
Discrete graphics card memory0.25 GB
Audio systemHD Audio
Audio includedHigh Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated dual-microphone array
Bluetooth version2.0+EDR
Networking featuresGigabit Ethernet, WLAN
Bundled softwareHP Recovery Manager, HP Client Manager Software, HP Client Configuration Management Agent, HP OpenView PC Configuration Management Solutions
Operating system installedWindows Vista Business
Optional operating system suppliedWindows XP Professional
Number of battery cells8
I/O ports4 USB 2.0; 1 1394a; 1 RJ-11; 1 RJ-45; 1 microphone in; 1 headphone/line-out; 1 docking connector; 1 HDMI; 1 battery connector; 1 eSATA
Charging port typeDC-in jack
Serial ports quantity0
USB 2.0 ports quantity4
AC adapter power120 W
Keyboard type101/102-key compatible keyboard with HP DuraKeys
Pointing deviceTouchpad + Scroll zone
CertificationENERGY STAR qualified
Storage drive type250 GB 7200 rpm SATA II
Video card featuresATI Mobility RadeonTM HD 3650
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Non-operating relative humidity (non-condensing)5 - 90 %
Processor codeSLGEK
Processor ARK ID35562
Processor package size35 x 35 mm
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth263.5 mm
Width355 mm
Weight2860 g
Height (front)28.2 mm
